Full Technical Specification
| Item | Specification |
|---|---|
| Product Name | Flammable Liquid Safety Storage Cabinet |
| Capacity | 45 US Gallon / 170 Litres |
| Application | Safe storage of flammable and combustible liquids |
| Cabinet Material | Heavy-duty steel |
| Steel Thickness | 18 Gauge / approx. 1.0 mm |
| Construction | Double-wall steel construction |
| Air Gap | 1.5 in / 38 mm between walls |
| Cabinet Color | Safety Yellow |
| Number of Doors | 2 |
| Door Type | Self-closing or manual-closing, depending on model |
| Door Opening | Up to 140° for self-closing models; manual models can open up to 180° |
| Locking System | 3-point stainless-steel latching system |
| Handle | Lockable safety handle |
| Shelves | 2 adjustable steel shelves |
| Shelf Adjustment | Typically 3 in / 76 mm centers |
| Shelf Load Capacity | Up to 350 lb / 159 kg per shelf on specified models |
| Spill Containment | Leak-proof bottom sump |
| Sump Height | Approx. 2 in / 51 mm |
| Ventilation Ports | 2 × 2 in / 51 mm ports, where fitted |
| Vent Protection | Fire baffles / flame arrestors and caps |
| Grounding | Grounding attachment provided |
| Finish | Chemical-resistant baked powder-coat finish |
| Warning Label | “FLAMMABLE – KEEP FIRE AWAY” |
| Certification | FM Approved on specified models |
| Compliance | OSHA and NFPA 30; some models also comply with NFPA 1 / IFC |
Main Safety Features
- Heavy-duty 18-gauge double-wall steel
- 1.5-inch insulating air space
- Two adjustable shelves
- Leak-proof bottom sump for spill containment
- Three-point locking mechanism
- Lockable handle
- Self-closing door option
- Dual ventilation ports with fire baffles where fitted
- Grounding connection
- Chemical-resistant powder coating
- Highly visible flammable warning label
- FM-approved configurations available
- Designed for storage of flammable liquids
